MECHANICAL
|
|
|
Dimensions
|
150 x 103 x 36 mm (5.9 x 4.1 x 1.4")
|
|
Weight
|
580 g (1.3 lb)
|
|
Enclosure material
|
Polycarbonate, aluminum
|
|
Mount material
|
Aluminum
|
|
HARDWARE
|
|
|
Networking interface
|
(1) 1/2.5 GbE RJ45 port
|
|
Management interface
|
Ethernet
|
|
Power method
|
PoE+
|
|
Power supply
|
UniFi PoE switch
|
|
Supported voltage range
|
44—57V DC
|
|
Max. power consumption
|
22W
|
|
Max. TX power
2.4 GHz
5 GHz
6 GHz
|
22 dBm
26 dBm
23 dBm
|
|
MIMO
2.4 GHz
5 GHz
6 GHz
|
2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
|
|
Max. data rate
2.4 GHz
5 GHz
6 GHz
|
688 Mbps (BW40)
4.3 Gbps (BW240)
5.7 Gbps (BW320)
|
|
Antenna gain
2.4 GHz
5 GHz
6 GHz
|
4 dBi
5 dBi
6 dBi
|
|
LEDs
|
White/blue
|
|
Button
|
Factory reset
|
|
Mounting
|
Wall (Included)
Table stand, flush mount (Optional)
|
|
Ambient operating temperature
|
-30 to 60° C (-22 to 140° F)
|
|
Ambient operating humidity
|
5 to 95% noncondensing
|
|
Certifications
|
CE, FCC, IC
|
|
SOFTWARE
|
|
|
WiFi standards
|
802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
|
|
Wireless security
|
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
|
|
BSSID
|
8 per radio
|
|
VLAN
|
802.1Q
|
|
Advanced QoS
|
Per-user rate limiting
|
|
Guest traffic isolation
|
Supported
|
|
Concurrent clients
|
300+
|
|
SUPPORTED DATA RATES
|
|
|
802.11a
|
6, 9, 12, 18, 24, 36, 48, 54 Mbps
|
|
802.11b
|
1, 2, 5.5, 11 Mbps
|
|
802.11g
|
6, 9, 12, 18, 24, 36, 48, 54 Mbps
|
|
802.11n
|
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
|
|
802.11ac
|
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
|
|
802.11ax (WiFi 6/6E)
|
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
|
|
802.11be (WiFi 7)
|
7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
|
|
Application Requirements
|
|
|
UniFi Network
|
Version 8.1 and later
|
|
UniFi OS
|
Version 3.2 and later
|
